Aluminum Laminated Film Lithium Ion Battery Materials

Overview

Basic Info.

Model NO.	GN- ALF
Thickness	113um
Width	400mm
Sadhesive(Polyester-Polyurethane)	PP/PE
Hardness	Soft
Transport Package	Roll
Specification	according customer requst
Trademark	Gelon
Origin	Shandong, China
Production Capacity	1000kg/Month

Product Description

Aluminum Laminated Film Lithium Ion Battery MaterialsProduct Description

Aluminum laminated film is one of the five major materials of lithium ion battery,and it is pouch lithium battery packaging material.The aluminum laminated film consists of outer nylon layer/adhesive/intermediate aluminum foil/adhesive/internal heat seal layer.
THICKNESS:88micron,113micron,153micron
WIDTH:400mm
LENGTH:300meters

Detailed Photos

Product Parameters

Product Specifications
Material	Aluminum Laminated Film ( Shodex)
Thickness	113μm
Width	400mm
Length	Length 7.5m 50m
Material & Composition
Polyamide (JIS Z1714)	0.025mm(+-0.0025mm)
Adhesive(Polyester-polyurethane)	4-5g/ m²
Aluminum foil (JIS A8079,A8021)	0.040mm(+-0.004mm)
Adhesive (Urethane-free Adhesive)	2-3g/m²
Polypropylene	0.040mm(+-0.004mm)
Quality inspection
Surface quality	Mat finish
Pinholes	Subject to the applicable aluminum foil standard
Impurity	1mm or less in diameter
Fish eye	2mm or less in diameter(clear),1mm or less in diameter(coloured)
Molding Depth	≥5.0mm
Electrical Insulating	Good
Heat Sealing Condition	180-190°C
